Product Features of high pressure pu machine:
1.Adopting three layer storage tank, stainless steel liner, sandwich type heating, outer wrapped with insulation layer, temperature adjustable, safe and energy saving;
2.Adding material sample test system, which can be switched freely without affecting normal production, saves time and material;
3.Low speed high precision metering pump, accurate ratio, random error within ±0.5%;
4.Material flow rate and presure adjusted by converter motor with variable frequency regulation, high accuracy, simple and rapid ration adjusting;
5.High-performance mixed device, accurately synchronous materials output, even mixture. New leakproof structure, cold water cycle interface reserved to ensure no blockage during long downtime;
6.Adopting PLC and touch screen man-machine interface to control the injection, automatic cleaning and air flush, stable performance, high operability, automatically distinguish, diagnose and alarm abnormal situation, display abnormal factors;
Butiran Cepat
Jenis Pemprosesan: Mesin Berbuih
Keadaan: Baru
Jenis Produk: Jaring Buih
Tempat asal: China (tanah besar)
Jenama: EMM
Voltage:380V
Power(W): About 9 KW
Dimension(L*W*H): 4100(L)*1250(W)*2300(H)mm
Berat: 1000Kg
Persijilan: CE
Waranti: 1 Tahun
Perkhidmatan selepas jualan yang disediakan: Jurutera yang tersedia untuk jentera perkhidmatan di luar negara
color:white
strength 1: self-cleaning filter
strength 2: automatic feeding system
strength 3: PLC control system
strength 4: precise metering
foam type: flexible foam/ rigid foam
output: 16-66g/s
tank volume: 120L
power: three-phase five-wire 380V
Name: foam injection molding machine
